Name: Whiteness Measurement Portable Spectrophotometer Colorimeter USB 20 Interface
Brand: CHN spec
Price: 1 USD

Whiteness Measurement Portable Spectrophotometer Colorimeter USB 2.0 Interface

Ask Lasest Price

Brand Name :

CHN spec

Model Number :

CS-286

Certification :

Price :

negotiable

Payment Terms :

T/T, Western Union, MoneyGram,Paypal

Supply Ability :

1000 per month

Delivery Time :

5-7 days

Whiteness Measurement Portable Spectrophotometer Colorimeter USB 2.0 Interface

Top Quality Whiteness Measurement Textile Color Difference Analysis Colorimeter

Textile Color Difference Analysis Colorimeter Specifications

Type	CS-286
Illumination	di/8(Diffused Illumination, 8 degree viewing)
Size of integrating sphere	Φ40mm
Illumination Light source	CLED
Sensor	array sensor
Wavelength	400-700nm
Spectrum Resolution	10nm
Measurement Time	2s
Measurement Aperture	11mm,optional 4mm,6mm,15mm
Repeatability	Standard Deviation ΔE*ab 0.08(when a white calibration plate is measured 30 x at 10-second intervals after calibration)
Observe Angles	2° and 10°
Light Source	A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,DLF,TL83,TL84,NBF,U30,CWF,U35
Display	Chromaticity value(Lab,LCh),delta E value,pass/fail,color tendency, average, generate test report,spectrum reflectance figure /data with Camera, reflectance figure, manual input target value
Color Difference Formula	ΔEab,ΔECH,ΔEuv,ΔEcmc(2:1),ΔEcmc(1:1),ΔE94,ΔE*00
Color Space	CIE-Lab,LCh, Luv ,XYZ,Yxy, reflectance
Other	WI(ASTM E313-10,ASTM E313-73,CIE/ISO,AATCC,Hunter,Taube Berger,Ganz,Stensby) YI(ASTM D1925,ASTM E313-00,ASTM E313-73) metameric index ,staining fastness , Color fastness Pantone color number matching function
Light Source Lifetime	5 years, 1.5 million times
Interface	USB2.0
Storage Temperature	-25~55℃, relative humidity 80% or below( at 35°C ),no condensation
Power	Rechargeable Lithium Battery 8.4V/2000mAh, adaptor DC12V
Size	77×86×210mm

Textile Color Difference Analysis Colorimeter Advantage

1). Spectro colorimeter:The highest precision colorimeter;

2). Patented technology guarantees measurement stability;

3). It comes with verification certification from 3rd party;

4). Large storage memory:100 pcs targets and 200 pcs samples;

5). Free Color QC software;

6). It can be used for color measurement of any kind of textile such as fabric, fiber, yarn,etc.

Textile Color Difference Analysis Colorimeter Packing List

Packing Material:Canvas bag with carton box

Packing Size:230x230x240mm

Packing Weight:2.4kgs

Delivery time:3-20 days after payment received

Qty.	Name	Qty.	Name
1	Main Instrument	1	Power Line
1	Operating Manual	1	USB Cable
1	Driving Software	1	Black/White Calibration Tiles
1	Color QC Software	1	Packing List
