Name: D8 Specular component Included SCI Handheld Color Meter Max
Brand: CHN spec
Price: 1 USD

D/8 Specular component Included SCI Handheld Color Meter Max

Ask Lasest Price

Brand Name :

CHN spec

Model Number :

colometer max

Certification :

Price :

negotiable

Payment Terms :

L/C, T/T, Western Union, MoneyGram

Supply Ability :

1000 per month

Delivery Time :

5-7 days

D/8 Specular component Included SCI Handheld Color Meter Max

ColorMeter MAX

D/8 Specular component Included SCI Handheld Color Meter Max

ColorMeter MAX is an enhanced version of the ColorMeter series. It is a powerful color measuring tool. Excellent performance configuration makes color measurement more accurate. The instrument can be wirelessly connected with Android or IOS devices, which greatly expands its application. It will take you into a new world of color management, which can replace the color card of printing, coating, textile, etc., realize the function of color test and find similar color; the instrument can pass the national metrology (Level II), and repeatability ≤0.05, better than ColorMeter Pro.

Part 1. Instrument Function Introduction

1. Measure Color Value

Adopt international used D/8 (Diffused Illumination, 8 degree viewing) geometry and SCI mode to make measurement more accurate.
Adopt spectral sensor to provide reflectance curve/data which make its performance much better than colorimeter.
It can measure whiteness index, yellowness index, color strength, color fastness, opacity and other 20 kinds of parameters with 26 kinds of illuminants.
“Pass” or “Fail” judgment can be directly seen from instrument screen.
It can pass the national metrology (Level II), repeatability ≤0.05, test accuracy 0.01 for accurate reading.

2. Portable and Massive Color Card Database

It supports connecting with mobile phone APP to create database to upload the color shades from printing, paint, textile color cards
No need to carry big and heavy color card, we can find color card database from Colormeter Max APP and find the closed/similar color easier and faster.

3. Artificial Intelligence for Accurately Measure Color

AI-based color search engine for accurately measure color;
Color can be collected anywhere and anytime.

4. Innovation Design for Auto Black and White Calibration

Auto instrument calibration for easier and correct color test
APP will remind for calibration if instrument works for long time
From APP we can do manual calibration and set calibration interval
Only 1s to see the test result which greatly improves working efficiency

5. Single Instrument for Test and Save Test Value

1.14 inches IPS display screen to show color information.
Data can be saved on instrument and instrument data can be synced into APP.

Operate on Instrument Operate by App

6. Cloud database, more convenient to view and upload

Official color card databases are available;
Personal users can update color information to cloud and share between different instruments which make color management much easier.
Enterprise users can create and manage their own color card library and formula information in the cloud and share the information to their customers and suppliers through the unique invitation code.

Part 2. Packing List

Name	Qty.
Instrument	1
Type-C Cable	1
Operate Manual	1

Part 3. Technical Data

Model	ColorMeter MAX
Illumination and Viewing System	D/8, SCI (specular component included)
Color Spaces, Color Difference and Indices	Reflectance, CIE-Lab, CIE-LCh, Hunter Lab, CIE-Luv, XYZ, Yxy, RGB, Color Difference (ΔEab, ΔEcmc, ΔE94, ΔE00), Whiteness Index (ASTM E313-00, ASTM E313-73, CIE/ISO, AATCC, Hunter, Taube Berger Stensby), Yellowness Index (ASTM D1925, ASTM E313-00, ASTM E313-73), Blackness Index(My,dM), Staining Fastness, Color Fastness, Tint(ASTM E313-00), Color Density CMYK(A,T,E,M), Metamerism Index Milm, Munsell, Opacity, Color Strength
Light Source	LED (Full Wavelength Balanced LED Light Source)
Test Aperture	8mm
Wavelength Interval	10nm
Wavelength Range	400-700nm
Repeatability	ΔE≤0.05 (when a white tile is measured 30 times at 5-second intervals after calibration)
Measurement Time	1s
Interface	USB
Illuminants	A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83,TL84
Observer	2°,10°
Display Screen	IPS Full Color Screen(135*240,1.14inch)
Battery	4.2V/760mAh,Rechargeable, 10,000 continuous tests
Language	English and Chinese
Calibration	Auto
Software Support	Andriod,IOS,Windows
Weight	About 90g
Instrument Size	Diameter 31mm , Height 102mm
Pass National Metrology (Level II)	Yes
Test Accuracy	0.01

Part 4. Detail Pictures

Part 5 Technical Support

1. One Year Warranty.

CHNSpec Technology （Zhejiang）Co.,Ltd. was found in 2008, and we are specializes in the R&D, production and sales of colorimeters, spectrophotoemters, haze meters, gloss meters and spectral analysis instruments, and is a leading producer in the color measurement field in China.Oue products have been widely used in plastic, electronic, paint, ink, textile, garment, printing and dyeing, food, medical, cosmetic, optical image test industries and the field of scientific research, school and laboratory..We are national high technology enterprise.Till September of 2018, Hangzhou CHNSpec Technology has received 11 invention patents ,3 software copyright patents and one American invention patent.In addition there are more than 10 invention patents in the announcement state. We have published more than 20 papers which more than 10 papers in SCI and EI and others are in the national first grade journal of science and research.

Our goal is to exceed the expectations of every client by offering outstanding customer service, increased flexibility, and greater value, thus optimizing system functionality and improving operation efficiency.We wish create value for customers and achieve win-win and common development and open a new era.

CHNSpec’s one-stop service gives you complete control over the sourcing, distribution, sales, delivery and after-sales services. In addition, our attention to detail and quality of work, paired with years of industry experience, make us your perfect partner to produce outstanding results. We also offer a significant security advantage to you as we are the only organization with trusted and experienced key staff involved in the product sales. It also means effective cost control and short lead times between sales and deliveries. We put customers upon everything else, and we are trying our best to satify your all needs.We sincerely support the best services for out customers

Our quality assurance program ensures that all products continuously conform to standards, from when it was sourced to when it is awaiting delivery at our warehouse. All of our products are being tested by QC and verified by 3rd party to ensure all the specifications are strictly met.

CHNSpec will always provide on time delivery. From order taking to deliveries, we ensure all products are sent out to esteemed customers on time. Before-sales and after-sales service is paramount to us, and constantly ingrained into our staff. All CHNSpec personnel are well-equipped with deep product knowledge and trained in the marketing and sales aspect of our products. Lastly, all product queries are important to us, no matter the size and scale of it.
