Name: Portable Color Measurement Spectrophotometer For Paints Color Matching
Brand: CHN spec
Price: 1 USD

Portable Color Measurement Spectrophotometer For Paints Color Matching

Ask Lasest Price

Brand Name :

CHN spec

Model Number :

CS-600

Certification :

Price :

negotiable

Payment Terms :

L/C, T/T, Western Union, MoneyGram

Supply Ability :

1000 per month

Delivery Time :

5-7 days

Portable Color Measurement Spectrophotometer For Paints Color Matching

Portable Color Measurement Spectrophotometer For Paints Color Matching

1. Brief Introduction of Spectrophotometer for Paints Color Matching

Our color spectrophotometers adopt high technology from overseas. It tests based on the condition of D/8 that is internationally used. Our device is widely used for color measurement for any industry especially for plastic,rubber,painting,textile,food,building material and other products’ color quality control.It could connect with color matching software to get recipes.

The following are the spectrophotometer for color measurement pictures.

color testing equipment

2. Application of Spectrophotometer for Paints Color Matching

1).It can be applied to laboratories, factories and others field that need color testing;

2).Allows medium and small companies to obtain high performance color management system;

The following are some of application of our spectrophotometers.

Portable Color Measurement Spectrophotometer For Paints Color Matching

3. Spectrophotometer for Paints Color Matching Longest Guarantee Time

color testing equipment for paint

a. One Year Guarantee Time.

b. If testing data is not correct, we can do refund.

c. We will provide testing report for every device to assure the authority of the data and it will save the calibration cost for 1 year.

4. Spectrophotometer for Paints Color Matching Technical Data

Type	CS-600
Illumination	d/8 (conform to CIE No.15,ISO 7724/1,ASTM E1164,DIN 5033 Teil7, JIS Z8722 Condition c standards)
Size of integrating sphere	Φ40mm
Illumination Light source	CLEDs
Wavelength Range	400-700nm
Wavelength Interval	10nm
Half spectral width	5nm
Reflectivity range	0-200%
Reflectivity resolution	0.01%
Observation angle	2°/10°
Measurement light source	A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,DLF,TL83,TL84,NBF, U30,CWF
Data being displayed	SPD distribution/data,sample's color values,color difference values/graph,pass/fail results,color error tendency,color simulation,display measurement area,history data color simulation,manual input standard sample,generate measurement report
Measurement time	1 second
Color space	CIE-Lab, LCh, Luv, XYZ, Yxy, Reflectance, Hunterlab,Munsell MI,CMYK
Color difference formulas	ΔEab, ΔECH, ΔEuv, ΔEcmc(2:1), ΔEcmc(1:1),ΔE94,ΔE*00, ΔEab(Hunter),555,color classification
Other colorimetric indices	WI(ASTM E313-10,ASTM E313-73,CIE/ISO, AATCC, Hunter, Taube Berger, Ganz, Stensby); YI(ASTM D1925,ASTM E313-00,ASTM E313-73);Tint(ASTM E313,CIE,Ganz) Metamerism index Milm, Stick color fastness, Color fastness, ISO luminance, 8 gloss, A density, T density
Repeatability	light splitting reflectivity:standard deviation within 0.08%
Repeatability	color values:ΔE*ab<=0.03(After calibration, standard deviation of 30 measurements on test white board, 5 second intervals), Maximum:0.05
Battery capacity	rechargeable, 10000 continuous tests, 7.4V/6000mAh
Data storage	20000 test results
Light source longevity	5 years, 1.5 million tests
Inter-instrument agreement	ΔE*ab within 0.2(BCRA color charts II, average of the 12 charts)
Size	18173112mm(LWH)
Weight	about 550g(does not include battery's weight)
Work temperature range	0~45℃, relative humidity 80% or below( at 35°C ),no condensation

5. Spectrophotometer for Paints Color Matching Packing List

color reading machine

Qty.	Name	Qty.	Name
1	Main Instrument	1	Power Line
1	Operating Manual	1	USB Cable
1	Driving Software	1	Black/White Calibration Tile
1	Color QC Software	1	Verification Certification
1	Packing List	1	Warranty Card
