Name: Easy Operated Portable Color Spectrophotometer ASTM D7843 Turbine Oils
Brand: CHN spec
Price: 1 USD

Easy Operated Portable Color Spectrophotometer ASTM D7843 Turbine Oils

Ask Lasest Price

Brand Name :

CHN spec

Model Number :

CS-600C

Certification :

Price :

negotiable

Payment Terms :

L/C, T/T, Western Union, MoneyGram

Supply Ability :

1000 per month

Delivery Time :

5-7 days

Easy Operated Portable Color Spectrophotometer ASTM D7843 Turbine Oils

ASTM D7843 Turbine Oils Portable Color Spectrophotometer Measure Instrument

Introduction:

Our color measuring machine is designed for measuring CIE-Lab, CIE-XYZ,density CMYK,etc.It adopts high technology from overseas. It tests based on the condition of 45/0 that is internationally used. Our device is widely used for color measurement for any industry especially for printing color quality control.

Specifications:

Type	CS-600C
Illumination	45/0,SCE(specular reflection excluded)
Size of integrating sphere	Φ40mm
Sensor	dual light path sensor array
Wavelength Range	400-700nm
Reflectivity resolution	0.01%
Observation angle	2°/10°
Measurement light source	A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,DLF,TL83,TL84,NBF,U30,CWF
Measurement time	1 second
Color space	CIE-Lab, LCh, Luv, XYZ, Yxy, Reflectance, Hunterlab,Munsell MI,CMYK
Color difference formulas	ΔEab, ΔECH, ΔEuv, ΔEcmc(2:1), ΔEcmc(1:1),ΔE94,ΔE*00, ΔEab(Hunter),555,color classification
Other colorimetric indices	WI(ASTM E313-10,ASTM E313-73,CIE/ISO, AATCC, Hunter, Taube Berger, Ganz, Stensby); YI(ASTM D1925,ASTM E313-00,ASTM E313-73);Tint(ASTM E313,CIE,Ganz) Metamerism index Milm, Stick color fastness, Color fastness, ISO luminance, 8 gloss, A density, T density
Repeatability	light splitting reflectivity:standard deviation within 0.08%
Repeatability	color values:ΔE*ab<=0.03(After calibration, standard deviation of 30 measurements on test white board, 5 second intervals), Maximum:0.05
Battery capacity	rechargeable, 10000 continuous tests, 7.4V/6000mAh
Light source longevity	5 years, 1.5 million tests
Inter-instrument agreement	ΔE*ab within 0.2(BCRA color charts II, average of the 12 charts)
Size	18173112mm(LWH)
Weight	about 550g(does not include battery's weight)
Work temperature range	0~45℃, relative humidity 80% or below( at 35°C ),no condensation

Applications:

It can be applied to laboratories, factories and others field that need color testing;

Allows medium and small companies to obtain high performance color management system;

The following are some of the application of our Spectrophotometers:

Competitive Advantage:

1). Obtained Metrology Accreditation Certificate in China

2). Large data storage space

3). Large TFT display screen

4). Modern and fashionable design based on human engineering

5). Easy to operate and compact operation interface

6). Pre-locating panel design for easy instrument calibration

7). Uses LED light source; high capacity rechargeable lithium-ion battery

8). Can measure both SCI(specular included)and SCE(specular excluded) at the same time

9). Includes PC software to manage data

10). Can connect to micro-printers for printing

11). Professional horizontal design and it does not have any moving parts, which avoids the shaking of the instrument during measurement process. This makes the measurement more accurate

12). PC software for easy measurement data management

13). Large data storage space: can store up to 100 sets of standard samples, with up to 200 measurement records for each standard sample
