CS-600 Portable Color Measurement CIE l*a*b Spectrophotometer
Wavelength 400-700nm
The DS-600 series spectrophotometer is supplied with a Windows
colour management system, ColorExpert, which
connects to the DS-600 series spectrophotometer via Bluetooth or
USB cable.
ColorExpert is a full-featured colour management software with four
functional modules: My Colours, Colour Check,
Colour Matching System and Personal Centre.
1. Brief Introduction of Color Spectrophotometer
Our color spectrophotometers adopt high technology from overseas.
It tests based on the condition of D/8 that is internationally
used. Our device is widely used for color measurement for any
industry especially for
plastic,rubber,painting,textile,food,building material and other
products’ color quality control.It could connect with color
matching software to get recipes. The following are the spectrophotometer for color measurement
pictures.
2. Advantages of Color Spectrophotometer
1). Obtained Metrology Accreditation Certificate in China
2). Large data storage space
3). Large TFT display screen
4). Modern and fashionable design based on human engineering
5). Easy to operate and compact operation interface
6). Pre-locating panel design for easy instrument calibration
7). Uses LED light source; high capacity rechargeable lithium-ion
battery
8). Can measure both SCI(specular included)and SCE(specular
excluded) at the same time
9). Includes PC software to manage data
10). Can connect to micro-printers for printing
11). Professional horizontal design and it does not have any moving
parts, which avoids the shaking of the instrument during
measurement process. This makes the measurement more accurate
12). PC software for easy measurement data management
3. Application of Color Spectrophotometer
1).It can be applied to laboratories, factories and others field
that need color testing;
2).Allows medium and small companies to obtain high performance
color management system;
The following are some of application of our spectrophotometers.
4. More Pictures of Color Spectrophotometer
5. Color Spectrophotometer Technical Data
| Type | CS-600 |
| Illumination | d/8(Diffused lighting, 8 degrees observe angle)(conform to CIE
No.15,ISO 7724/1,ASTM E1164,DIN 5033 Teil7, JIS Z8722 Condition c
standards) |
| Size of integrating sphere | Φ40mm,Alvan diffused reflection surface coating |
| Illumination Light source | CLEDs(entire wavelength balanced LED light source) |
| Wavelength Interval | 10nm |
| Reflectivity range | 0-200% |
| Reflectivity resolution | 0.01% |
| Observation angle | 2°/10° |
| Measurement light source | A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,DLF,TL83,TL84,NBF, U30,CWF |
| Data being displayed | SPD distribution/data,sample's color values,color difference
values/graph,pass/fail results,color error tendency,color
simulation,display measurement area,history data color
simulation,manual input standard sample,generate measurement report |
| Measurement time interval | 0.5 seconds |
| Measurement time | 1 second |
| Color space | CIE-L*a*b, L*C*h, L*u*v, XYZ, Yxy, Reflectance, Hunterlab,Munsell
MI,CMYK |
| Color difference formulas | ΔE*ab, ΔE*CH, ΔE*uv, ΔE*cmc(2:1), ΔE*cmc(1:1),ΔE*94,ΔE*00,
ΔEab(Hunter),555,color classification |
| Other colorimetric indices | WI(ASTM E313-10,ASTM E313-73,CIE/ISO, AATCC, Hunter, Taube Berger,
Ganz, Stensby); YI(ASTM D1925,ASTM E313-00,ASTM E313-73);Tint(ASTM
E313,CIE,Ganz) Metamerism index Milm, Stick color fastness, Color fastness, ISO
luminance, 8 gloss, A density, T density |
| Repeatability | light splitting reflectivity:standard deviation within 0.08% |
color values:ΔE*ab<=0.03(After calibration, standard deviation
of 30 measurements on test white board, 5 second intervals), Maximum:0.05 |
| Battery capacity | rechargeable, 10000 continuous tests, 7.4V/6000mAh |
| Light source longevity | 5 years, 1.5 million tests |
| Inter-instrument agreement | ΔE*ab within 0.2(BCRA color charts II, average of the 12 charts) |
| Size | 181*73*112mm(L*W*H) |
| Weight | about 550g(does not include battery's weight) |
| Work temperature range | 0~45℃, relative humidity 80% or below( at 35°C ),no condensation |
6. Certification for Color Spectrophotometer
7. Color Spectrophotometer Packing List
| Qty. | Name | Qty. | Name |
| 1 | Main Instrument | 1 | Power Line |
| 1 | Operating Manual | 1 | USB Cable |
| 1 | Driving Software | 1 | Black/White Calibration Tile |
| 1 | Color QC Software | 1 | Verification Certification |
| 1 | Packing List | 1 | Warranty Card |
